WIZMAX G-1650W 80plus Gold
WIZMAX G-1650W 80plus Gold - Image 1
WIZMAX G-1650W 80plus Gold - Image 2
WIZMAX G-1650W 80plus Gold - Image 3

WIZMAX G-1650W 80plus Gold

PSU

Available Colors:

BLACK
115V GOLD Full Modular ATX12V

Power Unleashed, Efficiency Perfected.

Experience the exceptional performance and reliability of WIZMAX PSU. Designed for optimal functionality and durability, this product delivers superior quality for all your computing needs.

WIZMAX G-1650W 80plus Gold Detail

General Specifications

80 PLUS Certification
115V GOLD
Form Factor
ATX12V
Modularity
Full Modular
Dimensions
150mm(W) x 180mm(D) X 86mm(H)

Fan Specifications

Fan Size
135mm
Fan Bearing
2-Ball Bearing
Fan Lifespan
70,000 hours

Connectors & Cables

Cable Type
Flat/Black
Main Connector
x1 (600mm)
CPU 4+4 PIN
x2 (750mm)
PCI-E 6+2 PIN
6+2 PIN : x2 (600mm) / (6+2)+(6+2) PIN : x2 (600mm + 150mm)
Sata
x12 (600mm + 150mm + 150mm + 150mm)
Ide
x6 (600mm + 150mm + 150mm)
Fdd
x1 (100mm)
Op Temp
~50°C
Protection
OVP, UVP, OPP, SCP, OTP, OCP, SIP, NLO
Certification
ErP Lot 6, RoHS
Voltage
100-120/120-240 V~
Current
16 A
Frequency
50-60 Hz
Rail
+3.3V, +5V, +12V, -12V, +5Vsb, + V & +3.3V
Max Power
25A, 25A, 137.5A, 0.3A, 3 A, 130W
Total Power
1650W (only 120-240 V~) / 1350W (only 100-120 V~)
WIZMAX G-1650W 80plus Gold - Gallery Image 1
WIZMAX G-1650W 80plus Gold - Gallery Image 2
WIZMAX G-1650W 80plus Gold - Gallery Image 3
⚡

80 PLUS Gold Certification

High efficiency power supply with 80 PLUS Gold certification ensures optimal power delivery and reduced energy waste, leading to lower electricity bills and cooler operation.

🔌

Fully Modular Design

The fully modular cable design allows you to use only the cables you need, reducing cable clutter and improving airflow inside your case for better cooling performance.
